Toshiba TB6560AHQ chip – High power, maximum 3.5A drive current chipset

Adjustable drive current settings for each axis – 25%,50%,75%,100% of full current can be set for different stepper motors

Overload, over-current and over-temperature safety – Full protection for your computer and peripheral equipment

Onboard current switching – Power output can be set according to specific user requirement

Full closed-type optical isolation to protect the user’s computer and equipment

Relay spindle interface – Outputs Max. 36V 7.5A for spindle motors or coolant pump (only one device can be powered by this output!)

4 channel inputs interface- Can be used for XYZ limit and emergency stop

Professional design – Two-stage signal processing with super anti-jamming

Bipolar constant current chopper drive with the non-resonant region – Controls motors smoothly through range without creep effect

Four control inputs (divided into pairs of knives) – Allows setting of limit and emergency stop

Universal architecture – Supports most parallel software MACH3, KCAM4, EMC2, etc!
